Steelhoard 25 Continuous System

Hoardings - Steelhoard 25 Continuous System

Our flagship hoarding system is the Heras Steelhoard 25 system. A continuous hoarding with a seamless fascia. Steelhoard 25 can be installed in ground spigots that are concreted in the ground making the posts fully re-usable or  erected as a free standing system above the ground using concrete ballast. All the systems components are designed to give 25 years of trouble free service making it the most sustainable hoarding system ever. The unique design means the components flatpack to a  small volume, minimizing storage space, with the additional benefit that it reduces transport costs giving it the lowest carbon footprint available. It can be reused time and time again and is therefore world leading in sustainability. It can also be transported and stored easily taking up a fraction of the space of conventional systems

Steelhoard 25 System Features

  • 25 year design life and the most sustainable hoarding on the market
  • Designed to be rapidly installed and dismantled
  • Heavy duty components withstand multi re use
  • Can be installed in ground or surface mounted
  • Flat pack components mean 500m can be carried on one vehicle
  • All components can be re used including posts
  • None mechanical parts guaranteed for 5 years
  • Component design ensures all parts are within manual lifting regulations for one person

Panel Sizes & Specification

  • Sheet Infill Height : 2440mm
  • Panel Width : continuous to elevation dimension
  • Posts: 89.9mm diameter, 2mm wall HT galvanized steel tube
  • Panels : Sheet thickness 0.9mm
  • Panels : Sheet finish polyester coating on pre-galvanized box profile sheet
  • Channels: 3mm galvanized steel channels
  • Panels: Can be powder coated to RAL colours to suit corporate requirements

A Full install, dismantle, service and storage facilities between projects is available on Steelhoard 25.

There are gates and a range of accessories to make the installation of the continuous system easy, safe and secure. View the range of continuous system accessories here
